Yingjie Technology linear narrow band sorting system is efficient, economical multi-functional sorting equipment, suitable for large goods, automatic sorting capacity, applicability, sorting capacity requirements of higher sorting scenarios. It is mainly used in logistics, express delivery, e-commerce and other industries. Narrow band sorting system has obvious advantages in large goods sorting, complex goods categories, large fluctuations in unloading efficiency and high flow requirements.
System Features
1. Compact footprint with easy maintenance and high cost-effectiveness;
2. Highly adaptable with flexible configurations;
3. Equipped with multi-side scanning system;
4. Standardized modular design implementation;
5. Accommodates diverse sorting needs for large, small, and non-standard items;
6. Seamless integration with client information management systems.
Technical Parameters
| Sorting efficiency | 8,000 – 12,000 pieces/hour |
| Operating speed | 2m/s – 2.5m/s |
| Standard pitch | 200mm |
| Mis-sorting rate | < 0.03% |
| Barcode recognition rate | 99.99% |
| Parcel dimensions | Max. 1200mm×900mm×700mm |
| Carrier load capacity | 0.05kg – 50kg |
| Floor space | 100m² – 500m² |
| Workforce requirement | 4 – 5 operators |
| Equipment investment | ¥500,000 – ¥1,500,000 (site-specific solutions may vary) |
